The MK-MF is the ideal solution for applications that exceed the operating range of our other series valves. Various end connections ranging from threaded (standard), buttweld, and flanged add versatility to this high-pressure product line. Special high nickel alloy constructions are available and round out the basic S31600/S31603 stainless steel offering.
This rugged Markco control valve is recommended for low-flow, high-pressure, industrial control applications. S31600/S31603 stainless steel barstock valve body and bonnet is suitable for process pressures up to 413 barg.
Features
Compact and light-weight design reduces installed piping costs.
Dual plug and stem guiding provides increased stability during plug travel.
Multiple trim capacity reductions available to meet changing process requirements with Cv ratings as low as 0.00013.
Optional extended bonnet for applications ranging from -195 to 537C (-320 to 1000 F).
Optional low leakage packing system to meet critical emission control requirements.
